metal tubular cattle/cow/horse fence rails galvanized livestock farm fence panel

FOB Reference Price:Get Latest Price
$11.55 - $40.55 / Pieces | 100 Piece/Pieces used livestock panels sample is available (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Fencing, Trellis & Gates
Place of Origin:
Hebei, China
Brand Name:
Shengyang
Model Number:
SY-0293
Frame Material:
Metal
Metal Type:
Iron
Pressure Treated Wood Type:
Chemical
Chemical Preservative Type:
ACQ (-B/C/D)
Frame Finishing:
hot-dipped galvanized
Feature:
Easily Assembled, Eco Friendly, Pressure Treated Timbers, Rodent Proof, Rot Proof
Frame Material::
metal
Metal Type::
Steel
Frame Finishing::
Hot-dipped galvanized
Corrosion form::
Electric galvanized,hot-dipped galvanized,powder coating
Frame::
32mm,40mm,42mm round tube,40x40mm & 50x50mm square tube
pins::
U & L
Width available::
2.07m,2.1m,2.25m,2.9m,3.5m
Rail size::
32mm OD,42mm OD,30X60mm &40x80mm oval rail tube
Height available::
1.6m,1.7m,1.8m,2.7m
Pressure Treated Wood Type::
Heat Treated
Supply Ability
Supply Ability:
1000 Set/Sets per Week
Packaging & Delivery
Packaging Details
1.In bulk: if it is 20ft container, then it can load more,and also it is hot dip galvanised. It will not be gamaged in the shiping period. 2.In high quality pallet 89pcs/steel pallet 3.According to the customer's requirement.
Port
xin'gang Tian'jin
Lead Time :
within 15 days after we recieve your deposit





Product Description



Description of livestock farm fence  panel

Materials: Carbon steel

Corrosion Form: hot-dipped galvanized or paint

Features: It can quickly and easily be installed, without the need to disturb the surface area by digging holes or laying foundations.

Main markets: Australia, European countries, Canada, America and Asia countries.

Description:

-1.8m high with 6 bars/rails or 1.6m high with 5 bars/rails.

-Complete with Caps & Foot plates.

-Holes for ground pin on one leg of each panel.

-Elongated lug holes in brackets, for ease when connecting.

Livestock farm fence panel Finish / Surface Treatment:

1). Wipe antirust paint on welding seams

2). Wipe antirust paint on welding seams + silver spray painted on the welding seams

3). Silver spray painted on the whole panel.

The popular specification of livestock farm  fence panel:

Specification Normal size
Height x Length 1.8m x 2.1m, 1.6 x 2.1m, 1.8m x 2.4m and so on
pole style Round pipe or square tube or oval tube
Pole specification 32mmO. D, 42mmO. D, RHS40mm, RHS50mm and so on
Package details In steel pallet or in bulk

livestock farm fence panel accessories:

1 set = 2 rain caps + 2 "U" lugs + 2 "L" lugs + 2 pins + 2 footplates

livestock farm fence panel Producing Process:

1). Pre hot dipped galvanized steel pipe -- welding -- polishing -- wipe antirust paint on welding seams

2). Pre hot dipped galvanzied steel pipe -- welding -- polishing -- wipe antirust paint on welding seams -- silver spray painted on the welding seams

3). Pre hot dipped galvanzied steel pipe -- welding -- polishing -- silver spray painted on the whole panel.

Welding Characters:

-- 360 degree firmly fully welded

-- Welding spots neat and smooth, prevent sheep and goat get hurt, very safe

-- Welding spots anti-rust finish, very durable

Unique Design:

-- Square vertical pipe/post, welding easy and firm, much durable, and it's more beatiful

-- Oval horizontal rails, no sharp edge, can protect sheep and goat from getting hurt, high safety

-- Lamb-proof rail spacing

-- Middle braces for high strength and heavy duty

-- With welded top caps and foot plates, water and dust proof

-- Welded "U" and "L" lugs for easy connection. The lugs are welded to bracket all four sides, very durable.

-- 2xjoining pins are supplied for each panel

-- Footplate on the panel,can cement the panels on the ground by nails.

-- Easily assembled & disassembled.

livestock farm  fence panel Features:

.The panels and gate are joined together with galvanised drop pins for a simple and easy set up.

The round yard is totally portable & can be easily assembled & disassembled to move or transport.

Although we have standard sizes the yard diameter can be made smaller or larger to your requirements using less or more panels.

.The material used to manufacture the panels and gates is new galvanised 42mm round pipe. We use this particular material as horse experts don't recommend the use of square shaped steel with corners such as SHS & RHS as this shape can lead to easy bruising, damage and injury to horse and rider. This size steel is also very visible to the horse.

Livestock farm fence Panel Gates -- Heavy Duty Swing Gates:

Height x Length 2200mm x 2000mm
Frame Horizontal & Vertical pipe: 50 mm x 50 mm RHS x 1.6 mm with fully welded caps
Cattle Gate Horizontal Rail 40 mm x 80 mm x 1.6mm thick x 6 oval anti-bruise rails "Bull bars" rails
Zinc Coating HDG - 15 microns
Finishing / Surface Treatment

1). Wipe antirust paint on welding seams

2). Wipe antirust paint on welding seams + silver spray painted on the welding seams

3). Silver spray painted on the whole panel

Welding Fully welded oval pipes, post & brackets , heavy duty hinges
Accessories Supplied with two HDG Bolt Pins with Nuts

b. Heavy duty Man-way Swing Gates :

Height x Inner Width 2200mm x 750mm / 800mm
Frame Horizontal & Vertical pipe: 50mm x 50mm RHS with fully welded caps
Cattle Gate Horizontal Rail 40mmx 80mm x 6 oval anti-bruise rails "Bull bars"
Finish HDG 15-microns
Welding Fully welded oval pipes, post &brackets, heavy duty hinges
Accessories Supplied with two HDG bolt pins with nuts

c. Heavy duty Sliding Gates:

Height x Inner Width 2200mm x 750mm / 800mm
Frame Horizontal & Vertical pipe: 50mm x 50mm RHS with fully welded caps
Horizontal Rail 40mmx 80mm x 6 oval anti-bruise rails "Bull bars"
Finish HDG 15-microns
Welding Fully welded oval pipes, post &brackets, heavy duty hinges
Accessories Supplied with two HDG bolt pins with nuts

Heavy duty race bow:

Height x Width 1800mm x 750mm / 800mm
Frame 40 x 40 x 1.6mm/2.0mm; 50 x 50 x 1.6mm/2.0mm
Finish HDG 15 - microns
Welding Fully welded brackets
Accessories Supplied with two HDG bolt pins with nuts

Sheep Yard Panel Joinning / Pinning System:

a. Sheep yard panels:

Materials HDG tubes, more than 15 microns Zinc coating on both inside and outside of the tubes
Material Sizes

30 x 30 x 1.6mm; 40 x 40 x 1.6mm gal square rails (SHS)

30 x 60 x 1.6mm; 40 x 80 x 1.6mm gal oval rails (Heavy duty)

Hight x Length 1.05m (H) x 2.16m / 2.8m (L)
Accessories

1). Unique "U" shaped zinc plated cleat:

a. The heavier panels have a 19mm round hole to fit a tapered 16mm zinc plated pin;

b. The lighter panels have a 14mm oval hole with a 12mm solid pin.

2) 1 set = 2 foot plates + 2 pins + (2 "U" lugs + 2 "L" lugs)/ 4 "U" lugs

Features

-- Low noise joinning system;

-- No sharp edges / protruding parts to hurt the Sheep;

-- 2 foot plates + 2 pins to allow the components to be pinned to the ground;

-- The pinning system at the top of the panels has been positioned so that sheep's legs cannot get caught between the posts.

b. Sheep yard gates:

Hight x Length: 1.05m (H) x 2.16m / 2.82m (L)

c. Sheep yard race gates:

Hight x Inner Length: 1.05m (H) x 550mm (L)



Packaging & Shipping



Standard export packing,or as your require.

Shipping:

sample is by air Express, and large order is by sea.

Payment terms:

30% TT in advance, 70% balance TT before loading.

Samples:

samples are available but you need pay for the sample price and freight fee.

the sample fee is returned after you place an order.

The delivert time is about 30days.

1> fence panel:plastic flim+wood/metal pallet

2> fence post:every post pack with a plastic bag(the cap is covered well on the post)+metal pallet

3> accessory:small plastic bag+carton box

4> we can also do as your details.



Company Information



ABOUT ShengYang:

Company name: Anping ShengYang Metal Wire Mesh Products Co., Ltd.

Area: 18980m2

No. of Employees: 40 people

Cartographers: 4,we can design drawing as clients requirement

Personnel for prepare sample:5

No. of QA/QC Inspector(s): 5 people

Export Markets: Europe, South America, Australia, North America, Asia etc.

Annual Revenue: USD14,724,000

Fencing certificates: CE certificate, ISO9001 certificate, SGS certificate, IAF certification, etc.

Straighten machine quantity: 20

Cutting machine quantity: 10

Welding machine quantity: 8

Bending machine quantity: 5

Sandblasting machine quantity: 2

Galvanized facility quantity: 2

Arkerizing tank quantity:1

Pvc coated machine quantity: 1

Pvc painted machine quantity:1





Our Services



The good service of livestock farm fence panel

Our after-sales service start immediately after signing the contract.

   .No matter FOB or CIF the price term

   .lowest freight cost for customers' reference.

   .The third-party inspection always gets real and true data from us

   .we will send production photos to customers if there is no inspection.

   .To help customer arrange the shipment and customs clearance.

   .Installation, maintenance and repair instructions with full information.

   .3-8 years warranty depends to different products.

   .Accept Changing or Refunding if the products cannot be installed rightly.





FAQ





Delivery Detail: within 8-12 days after receving deposit

Payment Term: 30% by T/T in advance, the balance by T/T against the fax copy of B/L.

Production Capacity: 79000 pieces per Month



Why choose US:

   .the best quality of plastic coating ( Akzo Nobel coatings )

   .galvanized coating (above 80g)

   .Select the high quality materials (from Shougang or other famous steel mill )

   .good tensile strength (at least 500 N)

   .there is a professional team to test the products on regular
